DC
DC Bilge Pump
Features
1、Small and easy to use.
2、DC Motor makes low noise and has a long service life.
Bilge Pump Application
Camping water discharge
- Boat water discharge
- 12V/24V application
| Model No. | DC Volt | AMP | Outlet | Pass Solid | Max Flow(LPM) | LPM Flow @ Head | Max Head(M) | Dimension | Weight | |||||
| mm | inch | Dia(mm) | 1M | 2M | 3M | 4M | 5M | L x W x H(mm) | Kg | |||||
| DC-1812 | 12 | 8 | 25 | 1" | 3 | 115 | 100 | 75 | 48 | 19 | - | 4.6 | 120.5 x 67 x 164.5 | 0.75 |
| DC-1824 | 24 | 5 | 25 | 1" | 3 | 115 | 100 | 75 | 48 | 19 | - | 4.6 | 120.5 x 67 x 164.5 | 0.75 |
| DC-2312 | 12 | 11 | 25 | 1" | 3 | 145 | 134 | 108 | 80 | 48 | 10 | 5.2 | 120.5 x 74 x 190 | 2.3 |
| DC-2324 | 24 | 5.5 | 25 | 1" | 3 | 145 | 134 | 108 | 80 | 48 | 10 | 5.2 | 120.5 x 74 x 190 | 2.3 |
| DC-3024 | 24 | 7 | 32 | 1-1/4" | 3 | 190 | 180 | 155 | 120 | 80 | 30 | 5.5 | 132 x 92 x 195 | 2.6 |
Recommend
HWCB
Revolutionary BLDC Macerating Toilet System
A cutting-edge solution designed to overcome toilet installation limitations.
Engineered to accommodate three distinct installation scenarios with ease.
Key Features
- Integrated ultra-quiet IP68-rated submersible BLDC grinder pump for continuous underwater performance
- High starting torque with constant speed and torque for reliable, jam-free operation
- Premium SUS440C grinder set (HRC55–60) ensures long-lasting durability
- Optional forced-reverse switch prevents clogging and maintains optimal flow
Technical Specifications
MH-FR
Floating Oil Scum Skimmer Pump
Product Overview
A new solution for floating oil and sludge removal.
The MH-FR Floating Scum Skimmer Pump is specially designed to collect and transfer surface oil, high-viscosity scum, and oily sludge from various types of wastewater. Ideal for wastewater treatment plants, industrial tanks, and coolant systems, this self-priming skimmer pump floats directly on the water surface and efficiently removes contaminants without the need for complex setups.
Key Features
Power Range: 1/3HP to 1HP (250W ~ 750W)
Floating Surface Skimmer Pump — Designed for collecting oil, scum, and floating debris
Self-Priming Function — Automatically draws in surface water for cleaning
Adjustable Depth — Easily adjust by adding water to the floats
High Efficiency — Removes high-viscosity scum, oily sludge, and floating oil from coolant tanks and wastewater
Floating Tree
Liquid temperature: 0~40℃ / 32~104℉
HP range : 1/2 HP / 400W
PH: 6~8
Motor insulation: B Class
Protection class: IPX8
Diameter: 1.5 / 2 inch (40 & 50mm)
Features
Easy assembly for the DIY market with modular connection.
Waterproof extension power cable junction box connects power cable for a suitable length with easy installation.
Easy installation and setting: Water depth limitation is 60cm.
Various nozzle patterns: Replace different patterns of nozzle easily.
- Suitable for surface aeration
