KT Water Cooled Construction Pump

Features:

The top of the water effectively cools the motor, to achieve the effect of motor cooling
The impeller is made of high chrome steel to achieve superior abrasion resistance

Application

General Construction
Civil Engineering
Tunnel & Subway Construction
Mining & Reclamation
Deep Well Pre-Dewatering
River Water Intake

Model	Output		Outlet		Max Flow (LPM)	LPM FLow@ Head					Max Head (M)	Weight (KG)
Model	HP	KW	mm	inch	Max Flow (LPM)	5M	10M	15M	20M	25M	Max Head (M)	Weight (KG)
KT-215	2	1.5	50	2"	505	490	420	325	165	-	22	33
KT-222	3	2.2	50	2"	670	660	610	530	400	140	26	38
KT-237	5	3.7	50	2"	550	545	535	520	500	450	37	68

Model	Output		Outlet		Max Flow (LPM)	LPM FLow@ Head					Max Head (M)	Weight (KG)
Model	HP	KW	mm	inch	Max Flow (LPM)	5M	10M	15M	20M	25M	Max Head (M)	Weight (KG)
KT-315	2	1.5	80	3"	550	505	350	-	-	-	15	33
KT-322	3	2.2	80	3"	800	760	620	430	180	-	22	38
KT-337	5	3.7	80	3"	760	750	725	680	600	480	32	68
KT-355	7.5	5.5	80	3"	1360	1340	1280	1200	1070	910	36	78

Model	Output		Outlet		Max Flow (LPM)	LPM FLow@ Head					Max Head (M)	Weight (KG)
Model	HP	KW	mm	inch	Max Flow (LPM)	10M	20M	30M	40M	50M	Max Head (M)	Weight (KG)
KT-437	5	3.7	100	4"	1430	1100	-		-	-	19	68.5
KT-455	7.5	5.5	100	4"	1940	1650	910	-	-	-	22	77
KT-475	10	7.5	100	4"	1550	1500	1370	980	-	-	39	136.5
KT-4110	15	11	100	4"	1450	1420	1340	1140	560	-	45	144
KT-4150	20	15	100	4"	1930	1920	1890	1780	1400	280	52	160

Model	Output		Outlet		Max Flow (LPM)	LPM FLow@ Head					Max Head (M)	Weight (KG)
Model	HP	KW	mm	inch	Max Flow (LPM)	5M	10M	15M	20M	25M	Max Head (M)	Weight (KG)
KT-675	10	7.5	150	6"	2050	1960	1760	-	-	-	28	139
KT-6110	15	11	150	6"	2480	2395	2000	1100	-	-	34	144
KT-6150	20	15	150	6"	2950	2930	2760	2250	1200	-	45	165
