JA
Key Feature
1、Automatic flow switch patent design.
2、Stainless steel pump casing, no leaking issue.
3、Removable flow switch, easy to clean and install.
4、JA-80S can endure temperatures up to 60°C.
1、Domestic booster water heater
2、Water pipe recirculation system
| Model No. | JA-80(S) | ||
| HZ | 50Hz | 60Hz | |
| Output | HP | 1/10 | 1/10 |
| W | 80 | 80 | |
| Outlet | mm | 20 | 20 |
| inch | 3/4" | 3/4" | |
| Pass Solid | Dia(mm) | 1 | 1 |
| Max. Flow (LPM) | 23 | 26 | |
| LPM Flow @ Head | 1.5M | 22 | 25 |
| 3M | 20 | 22 | |
| 4.5M | 16 | 18 | |
| 6M | 11 | 13 | |
| 7.5M | 4.5 | 8 | |
| Max Head(M) | 8.5 | 10 | |
| Dimension (mm) L x W x H | 236 x 107 x 127 | 236 x 107 x 127 | |
| Weight (KG) | 3.5 | 3.5. | |
Recommend
SW-60/120/250
Feature
1、Clean water: all the materials contacting water is stainless steel.
2、Low noise: the newly designed vortex fan can reduce the noise.
3、Suitable for outdoor environment(IP55).
4、 A high-quality mechanical seal can endure the high temperature up to 90℃.(SW-120S/250S)
MVH-10E
The MVH‑10E Submersible Booster Pump from Hung Pump is designed for automatic pressurized water systems, particularly in rainwater harvesting and non‑negative pressure applications. It incorporates dry-run protection to safeguard the pump during water shortages, and features an automatic restart function when water flow resumes. Maintenance is streamlined with its modular pressure switch and circuit board, allowing for quick repairs and customizable operational parameters
Features
• Automatic pressurized water supply proper for Rain Harvesting system and Non-negative Pressure Water Supply system.
• Dry-run protection in no water conditions and an Automatic wake-up function when water is cut off.
• Simple Maintenance: The Modular pressure switch & circuit board can be easily replaced and repaired.
• Customized Parameters: All parameters mentioned
SPB
Brushless DC SWIMMING POOL PUMP
• Pool Operation Status: Suggested Speed for the operation status
• Pool Filtration system: Lowest Speed 900RPM
• Pump Quick self-clean: Max Speed range 1726 ~ 3450 RPM
• Pool Cleaning and sand filter cylinder backwash: Max Speed
range 1726 ~ 3450 RPM
• Complied with the US Department of Energy (DOE) standard.
SP-4 Inch
Key Features of SP
- Sand-Resistant Design
- Durable Stainless Steel Construction
- High Efficiency and Reliable Operation
SP-6 Inch
SP Series Sand Prevention Submersible Borehole Pumps are constructed from high-quality stainless steel for enhanced durability and extended service life. The specially engineered impeller and diffuser design allow the pump to handle water containing up to 1% sand without damage. This advanced design ensures excellent energy efficiency and high-performance pumping, making it ideal for deep well water supply, irrigation, and industrial applications. With its easy installation and low maintenance requirements, the SP Series is a reliable solution for challenging borehole conditions.
Key Features of SP
- Sand-Resistant Design
- Durable Stainless Steel Construction
- High Efficiency and Reliable Operation
SP-8 Inch
SP Series Sand Prevention Submersible Borehole Pumps are constructed from high-quality stainless steel for enhanced durability and extended service life. The specially engineered impeller and diffuser design allow the pump to handle water containing up to 1% without damage. This advanced design ensures excellent energy efficiency and high-performance pumping, making it ideal for deep well water supply, irrigation, and industrial applications. With its easy installation and low maintenance requirements s, the SP Series is a reliable solution for challenging borehole conditions. FEATURES
- Corrosion resistant, Non-polluting, stainless steel construction — inside and out.
- Built-in jam-free stainless steel check valve will effectively prevent backflow of water in the pipe from affecting pump performance when the motor is not operating.
- Precision stainless steel intermediate chamber can help maintain optimum performance even when pressure is greatest.
- The high-performance, highly efficient stainless steel impellers are one of the special features of our submersible pump. It is incomparably superior to ordinary plastic or brass impellers in terms of abrasion resistance and service life.
- The stainless steel strainer can prevent the entry of sand or other extraneous material. The smooth safety hook will prevent the cable from abrading.
APPLICATION
- Supply of raw water for households
- Supply of water from the wells to the reservoir
- Irrigation, Plantation, and Agriculture
- Industrial and municipal application
