JK Series – Non-Clogging Submersible Sewage Pump
The JK Series from Hung Pump is a high-efficiency submersible sewage pump designed for non-blocking operation in wastewater applications. Engineered with a non-clogging impeller and advanced slippage casing, it ensures smooth flow and energy-saving performance—ideal for both municipal and industrial use.
Key Specifications
- Liquid Temperature: 0~40°C
- Horsepower Range: 0.5~7.5 HP / 0.4~5.5 kW
- pH Range: 6~8
- Rated Speed: 2-Pole Motor – 2900 RPM (50Hz) / 3450 RPM (60Hz)
- Protection Class: IPx8
- Maximum Depth: 10 meters
Product Features
- Non-clogging vortex impeller: Prevents blockage and maintains stable flow.
- Smooth flow slippage casing: Designed for low resistance and energy efficiency.
- Suspended impeller design: Improves hydraulic performance and prevents clogging.
- H-Class motor winding: High thermal resistance for long-term operation.
The JK Series is ideal for wastewater pits, pumping stations, and sewage systems where clog-free performance and low power consumption are essential.
Industrial sewage discharge
Model No. | Output | Outlet | Pass Solid | MaxFlow(LPM) | LPM Flow @ Head | Max Head(M) | Dimension | Weight | ||||||
HP | KW | mm | inch | Dia(mm) | 3M | 6M | 9M | 12M | 15M | L x W x H(mm) | Kg | |||
JK-05 | 1/2 | 0.4 | 50 | 2" | 30 | 320 | 285 | 190 | - | - | - | 9 | 223 x 132 x 395 | 14 |
JK-10 | 1 | 0.75 | 50 | 2" | 30 | 400 | 360 | 270 | 160 | - | - | 12 | 320 x 162 x 460 | 21 |
JK-20 | 2 | 1.5 | 80 | 3" | 35 | 620 | 600 | 550 | 490 | 410 | 280 | 18 | 387 x 210 x 560 | 32 |
Model No. | Output | Outlet | Pass Solid | MaxFlow(LPM) | LPM Flow @ Head | Max Head(M) | Dimension | Weight | ||||||
HP | KW | mm | inch | Dia(mm) | 3M | 5M | 10M | 15M | 20M | L x W x H(mm) | Kg | |||
JK-30 | 3 | 2.2 | 80 | 3" | 35 | 780 | 755 | 720 | 610 | 420 | - | 18 | 387 x 210 x 580 | 34 |
JK-50 | 5 | 3.7 | 100 | 4" | 50 | 1100 | 1050 | 980 | 800 | 590 | 250 | 22 | 475 x 216 x 630 | 45 |
JK-75 | 7.5 | 5.5 | 100 | 4" | 50 | 1200 | 1170 | 1120 | 960 | 770 | 490 | 24 | 475 x 216 x 660 | 54 |
