GS Progressive Cavity Grinder Pump Series
Features
- The cutter material is SUS440C.
- All cast-iron sewage pumps. Highly efficient heat-conducting material.
- All cast-iron seal plates with a double mechanical seal. No leaking issue.
- The Screw impeller can transfer highly viscous liquid for a high head.
- Positive displacement
- H-Class Motor Winding
- Perfect for low-pressure sewer application
- Low Speed High Torque, Completed with 4 Pole Motor
GS Sewer Grinder Pump Application
- Sewage/Sewer and black water disposal
- Animal husbandry, sewage, and wastewater disposal
- Leather factory sewage disposal
- Wastewater treatment plant
GS Screw Specification
| Model No. | Output | Outlet | Max Flow(LPM) | LPM Flow @ Head | Weight | Standard accessories | ||||||
| HP | KW | mm | inch | 10M | 20M | 30M | 40M | 50M | Kg | |||
| GS-15 | 1.5 | 1.1 | 32 | 1-1/4" | 50 | 45 | 37 | 32 | 25 | 20 | 42 | 1-1/4" elbow, 1-1/4" flange |
GS Dimension
GS Performance Curve
GS 3D Sectional Drawing
Recommend
GDH
Key Feature
- The Cutter Material is HCR(High Chrome).
- Stainless Steel Motor housing.
- High-head Grinder Pump.
- H-Class Motor Winding
- Double Bearing for Longer Service Life
GC
Feature
1、The cutter material is SUS440C.
2、All cast-iron sewage pumps. Highly efficient heat-conducting material.
3、All cast-iron seal plates with double mechanical seals. No leaking issue.
| Liquid temperature | 0~40℃ / 32~104℉ | ||
| HP range | 0.7~7.5HP / 0.55~5.5KW | ||
| PH | 6~8 | ||
| Rated Speed | 2900 / 3450 rpm | ||
| Protection class | IPX8 | ||
| Maximum depth | 8M | ||
GCB
Feature
- High starting torque/ constant speed/ constant torque motor design ensures the pump runs without jamming.
- High energy-efficient pump technology to save you on electricity costs.
- Extremely Silent Submersible BLDC Grinder Pump.
- High hardness SUS440C (HRC55~60) Cutter Design.
- Lightweight and portable Unique compact Size design for the narrow pits or sumps.
- Soft Start
- Reverse Jog when the cutters clog
LT-030GB
BLDC Floodable Grinder Lifting Station
- Power Range: 1 ~ 2 HP (750W ~ 1.5kW)
- Tank Size: 30L / 60L
- Compact, quiet, and reliable — the LT-030GC is ready to use with no need for excavation or masonry work.
- Pre-assembled grinder lifting system designed to collect and pump wastewater from residential:
- Wash basins
- Toilets
- Showers
- Washing machines
