SB
SB
Technical Specifications
- Liquid Temperature: 0~40°C
- Horsepower Range: 0.5~7.5 HP / 0.4~5.5 kW
- pH Range: 5~9
- Rated Speed: 2-Pole, 2900 / 3450 RPM
- Protection Class: IPX8
- Maximum Submersion Depth: 10 meters
Key Features
- Non-clogging vortex impeller ensures smooth operation with minimal blockage.
- Suspended impeller with high-efficiency flow channel; capable of passing solids up to 50mm.
- Durable stainless steel (316/304) construction that resists light acid and alkali corrosion.
- Designed for sewage and corrosive liquid applications.
- Low maintenance and long-lasting performance.
SB Stainless Steel Sewage Pump Application
1. Sewage treatment plants
2. Chemical wastewater systems
3. Pharmaceutical and food industry waste
4. Municipal and industrial drainage
5. Laboratory & Medical Facilities
6. Coastal, Marine, and Seawater Applications
50&60 Hz
SB Stainless Steel Sewage Pump Specification | ||||||||||||||
| Model No. | Output | Outlet | Pass Solid | Max Flow(LPM) | LPM Flow @ Head | Max Head(M) | Dimension | Weight | ||||||
| HP | KW | mm | inch | Dia(mm) | 3M | 6M | 9M | 12M | 15M | L x W x H(mm) | Kg | |||
| SB-05 | 1/2 | 0.4 | 50 | 2" | 30 | 320 | 290 | 180 | 50 | - | - | 10 | 223 x 132 x 395 | 14 |
| SB-10 | 1 | 0.75 | 50 | 2" | 30 | 410 | 370 | 250 | 100 | - | - | 12 | 223 x 132 x 425 | 21 |
| SB-20 | 2 | 1.5 | 80 | 3" | 35 | 630 | 600 | 550 | 490 | 410 | 280 | 18 | 390 x 210 x 530 | 32 |
| Model No. | Output | Outlet | Pass Solid | Max Flow(LPM) | LPM Flow @ Head | Max Head(M) | Dimension | Weight | ||||||
| HP | KW | mm | inch | Dia(mm) | 3M | 5M | 10M | 15M | 20M | L x W x H(mm) | Kg | |||
| SB-30 | 3 | 2.2 | 80 | 3" | 35 | 800 | 755 | 720 | 610 | 420 | - | 18 | 390 x 210 x 550 | 34 |
| SB-50 | 5 | 3.7 | 100 | 4" | 50 | 1100 | 1050 | 980 | 800 | 590 | 250 | 22 | 525 x 250 x 635 | 45 |
| SB-75 | 7.5 | 5.5 | 100 | 4" | 50 | 1200 | 1170 | 1120 | 960 | 770 | 490 | 24 | 525 x 250 x 675 | 54 |
SB Stainless Steel Sewage Pump Dimension
SB Stainless Steel Sewage Pump Performance Curve
SB Stainless Steel Sewage Pump 3D Sectional Drawing
